DC Volts Ranges |
1000 mV, 10 V, 100 V, 1500 V |
DC Volts Resolution |
0.1 mV in 1000 mV range |
DC Volts Accuracy |
± (0.1% of reading + 5 digits) |
DC Volts Input Impedance |
10 MΩ |
DC Volts CMRR |
> 120 dB up to 1500 Vdc |
DC Volts NMRR |
> 60 dB at 50 or 60 Hz |
DC Volts OL Protection |
1500 Vdc or 1000 Vac RMS |
DC Volts Transient Protection |
12 kV impulse (1.2 μs/50 μs) based on EN 61010-1:2001 impulse requirement for at CAT IV 1000 V/1500 Vdc product. This product should not be used in installations where transients exceed 12 kV. |
DC Current Ranges |
100 μA, 1000 μA, 10mA, 100mA, 400mA, 2A (Auto/Manual ranging) |
DC Current Resolution |
0.01μA in 100 μA range. |
DC Current Accuracy |
100 μA range ± (0.5% of reading + 10 digits) 1000 μA to 400 mA ranges ± (0.5% of reading + 5 digits) 2 A range ± (1.5% of reading + 10 digits) |
DC Current Input Protection |
2A/1500V fast blow ceramic fuse, 8×65 mm on A input, FP700 |
AC Volts True RMS Ranges |
1000 mV, 10 V, 100 V, 1000 V |
AC Volts True RMS Resolution |
0.1 mV in 1000 mV range |
AC Volts True RMS Accuracy |
1000 mV (45 Hz to 400 Hz): ± (1.2 % of reading + 10 digits) 10 V, 100 V (45 Hz to 500 Hz): ± (1.2 % of reading + 10 digits) 10 V, 100 V (500 Hz to 2 kHz) ± (2.0 % of reading + 10 digits) 1000 V (45 Hz to 1 kHz) ± (2.0 % reading + 10 digits) |
AC Volts True RMS Input Impedance |
10 MΩ |
AC Volts True RMS Conversion Type |
True RMS, ac coupled 5 % to 100 % of range |
AC Volts True RMS Crest Factor |
≤ 3 |
AC Volts True RMS OL Protection |
1500 V dc or 1000 V ac RMS |
Resistance Rages |
200 Ω, 2 kΩ, 20 kΩ, 200 kΩ, 2 MΩ, 20 MΩ |
Diode Test |
1.0 mA, 3 Vdc |
Temperature Measurement |
-20°C to 1300°C (-4°F to 2372°F) |
Continuity Test |
Audible sound at <50 Ω ± 25 Ω, 100 ms |
Transient Protection |
12 kV impulse (1.2 μs/50 μs) based on EN 61010-1:2001 impulse requirement for at CAT IV 1000V product. This product should not be used in installations where transients exceed 12 kV. |
Battery Life |
150 hours, alkaline |
Dimensions |
200 x 102 x 59 mm (7.9" x 4.0" x 2.3") |
Weight |
642 g (22 oz) with battery |
Safety |
Meets EN 61010-1 CAT IV 1000 V (1500 V DC max) Class II, EN 60529:IP67 |
