材料 |
厚度 |
电流 |
最大切割速度 | ||||
|
(英寸) |
(mm) |
(A) |
(ipm) |
(mm/min) | ||
|
0.048 (18 Gauge) 0.074 (14 Gauge) 1/8 |
1.2 1.8 3.1 |
50 50 50 |
160 120 60 |
4,060 3,050 1,520 | ||
1/8 1/4 1/2 3/4 |
3.1 6.2 12.4 20 |
100 100 100 100 |
240 120 60 30 |
6,100 3,050 1,540 760 | |||
1/4 3/8 1/2 3/4 1 1 1/4 1 1/2 2 |
6.2 10 12.4 20 25 32 38 50 |
200 200 200 200 200 200 200 200 |
230 140 120 75 50 30 20 10 |
5,800 3,500 3,000 1,900 1,300 760 500 250 | |||
|
1/8 1/4 1/2 |
3.1 6.2 12.4 |
100 100 100 |
140 80 35 |
3,560 2,030 890 | ||
1/4 3/8 1/2 3/4 1 1 1/4 1 1/2 |
6.2 10 12.4 20 25 32 38 |
200 200 200 200 200 200 200 |
195 145 105 55 30 15 10 |
5,000 3,700 2,700 1,400 760 380 250 | |||
1/4 1/2 3/4 1 1 1/2 |
6.2 12.4 20 25 38 |
200 200 200 200 200 |
62 42 32 22 11 |
1,600 1,100 810 560 280 | |||
|
1/8 1/4 1/2 |
3.1 6.2 12.4 |
100 100 100 |
110 70 40 |
2,800 1,780 1,010 | ||
1/4 1/2 3/4 1 1 1/4 1 1/2 |
6.2 12.4 20 25 32 38 |
200 200 200 200 200 200 |
190 110 65 35 20 12 |
4,800 2,800 1,650 900 500 300 |
输入电压 |
200 V, 3 PH, 50 Hz; 208 V, 3 PH, 60 Hz; 220/380/415 V, 3 PH, 50 Hz; 240/480 V 3 PH 60 Hz; 600 V, 3 PH, 60 Hz |
输入电流 |
108 A, 200 V; 104 A, 208 V; 98/57/52 A, 220/380/415 V; 90/45 A, 240/480 V; 36 A, 600 V |
输出电压 |
150 VDC |
输出电流 |
40 - 200 A |
负载持续率 |
100% |
最大空载电压 |
280 VDC |
尺寸 |
41.25" (1040 mm) D; 28.25" (710 mm) W 35.5" (900 mm) H |
重量 |
780 lbs. (351 kg) |
气源
|
O2, Air, N2, Ar-H2 120 psi (8.3 bar) 80 scfh (40 l/min.) |
气体流量
|
O2, Air, N2, Ar-CO2 90 psi (6.2 bar) 280 scfh (130 l/min.) |
|
Mild Steel |
Stainless Steel |
Aluminum | |
Plasma gas/shield gas |
O2/Air |
Air/Air |
Air/Air | |
Cut thickness range |
.048" - 2.0" (1.2 - 50 mm) |
125" - 1.5" (3.2 - 38 mm) |
.125 "- 1.5" (3.2 - 38 mm) | |
Dross-free range |
.048" - 1" (1.2 - 25 mm) |
.125" - .75" (3.2 - 19 mm) |
.125" -. 75" (3.2 - 19 mm) | |
Maximum piercing thickness |
1.5" (38 mm) |
.875" (22.2 mm) |
.875" (22.2 mm) | |
Range of production cutting |
50A |
.048" -.125" (1.2 - 3.2mm) |
N/A |
N/A |
100A |
.125"-.375" (3.2 - 9.5 mm) |
.125"-.375" (3.2 - 9.5 mm) |
.125"-.375" (3.2 - 9.5 mm) | |
200A |
.25"-1.0" (6.4 - 25.4 mm) |
.25"-.875" (6.4 - 22.2 mm) |
.25"-.875" (6.4 - 22.2 mm) | |
Range of kerf angle |
0° - 5° |
0° - 5° |
0° - 5° |
产品名称 | 产品简介 | 产品编号 |
---|---|---|
HT2000等离子切割机 | MW-03035-00 |
