订货号: | MM-11329-00 |
产地: | 日本 |
品牌: | |
开发编号: | N |
市场价: | ¥ |
*此产品根据配置不同价格不同 |
*此价格为参考价格,具体价格以订单合同为准 |
|
|
P/N |
Type |
Description |
FV |
ANALOG OUTPUT for recording and data acquisition |
Provides 0-10 V DC or 4-20 mA output proportional to the input frequency. A 12-bit D/A converter is used. |
CP |
RELAY CONTACT for alarms and control systems |
Provides 3 separate SPST relay contacts working in conjunction with the HI, GO & LO LED's on the front panel. |
Operating Mode: |
Rate Measurement |
Elapse Time Counter |
Display Selections: |
0-9.9999 |
99.99 seconds |
0-99.999 |
99 minutes 59 seconds | |
0-999.99 |
99 hours 59 minutes | |
0-9,999.9 |
| |
0-99,999 |
| |
Measuring Range: |
10-99,999 rpm (@ 1 pulse per rev.) | |
0.2-30,000 rpm (@ 60 pulses per rev.) | ||
Display: |
5-digit LED, 0.56" (14.2 mm) high | |
Accuracy: |
± 0.008% or ± 1 digit | |
Number of PPR: |
1-9,999 pulses/rev (selectable) | |
Input Signal Maximum Frequency: |
Sine wave: 10kHz | |
Square wave: 30kHz | ||
Open Collector: 30kHz | ||
Contact closure: 20Hz | ||
Input Signal Amplitude: |
Sine wave: 0.3-30 V P-P | |
Square wave: LO: 0-1.5 V, HI: 4-30 V | ||
Input Impedance: |
10 k-Ohms for magnetic pickup, rotary pulse generator and proximity switch | |
Voltage Output |
12 V DC ±5% (50 mA max.) to power sensors | |
Applicable Sensors: |
Rotary pulse generator, magnetic pickup, proximity switch, retro-reflective optical | |
Ambient Temperature: |
32º - 113º F (0-45º C) | |
Power Consumption: |
1 W (5 W when optional modules are used) | |
Voltage Requirement: |
85-265 V AC, 50/60Hz Option 24VDC for 9-35V DC | |
Dimensions: |
3.46" L x 1.88" H x 3.78" D (8 L x 48 H x 96 D mm) includes bezel and fits 1/8 DIN cutout | |
Weight: |
0.55 lbs. (250 g) | |
Cutout Dimensions: |
92W X 45H (mm) |
定货号 | 产品名称 | 规格配置 / 简介 | 市场价/(会员价) |
---|---|---|---|
MM-11329-00 | DT-5TG多用途转速计 | /() |
