PK2X-AC频闪仪
PK2X-AC频闪仪
订货号: MM-10425-00
产地: 美国
品牌:
开发编号: N
市场价:
*此产品根据配置不同价格不同
*此价格为参考价格,具体价格以订单合同为准
    我在现场:
    产品视频:

所有产品分类

工业检测设备

机械检测/设备巡检

  • 红外测温仪
  • 机械状态检测
  • 激光对中仪
  • 设备状态巡检仪(162)
  • 测功器/油耗仪
  • 频闪仪(110)
  • 测振仪(255)
  • 超声波巡检仪(30)
  • 设备状态检测
  • 转速表(265)
  • 产品描述
  • 技术参数
  • 技术文档
  • 相关产品
  • 明细价格
  • 购买流程
产品描述:

The new PK2X-AC hand-held Portable Strobe® is convenient and accurate device to perform non-contact RPM measurements on rotating or reciprocating parts or components as well as a proven means for inspection of moving parts/machinery by “freezing” or “slowing down” the action. This stroboscopic effect is accomplished by matching the flash rate of the stroboscope with the repetitive rate (RPM) of motion of the target. A slow motion effect is accomplished with a slight mismatch of the relative speeds.
The PK2X-AC is powered directly from an AC power source allowing for continuous use. It small size, lightweight design makes it perfect for use by field technicians or maintenance personnel.
The new PK2X-AC offer significant improvements from the previous generation model PK2 including a 50% improvement in flash brightness.
This new model continues to offer the highest reliability, refined by over 10-years of continuous design & manufacturing improvements since the introduction of the original Pocket Strobe Model PK1 was introduced in 1996.
The PK2X-AC requires only one hand to operate, yet delivers performance comparable to much larger and heavier “pistol-grip” type models. It is ideal for industrial, laboratory, R&D and academic environments. Its small size and excellent performance provide superior convenience and value — at a reasonable price.

sh Range
30 - 12,500 FPM
Flash Brightness
1200 Lux (8"/20cm distance @ 4500 fpm)
Accuracy
± 0.01% over entire range + 1 LSD
± 0.04 Hz
Resolution
± 1 FPM over entire range
Display
5-digit LCD
Display Update
0.5 seconds
Flash Energy
170 mJ
Flash Duration
< 9 µs
Flash Tube Life
200 million flashes (at 6,000 fpm)
Flash Color Temp
6,000K - 6500K
External Trigger
0-5 volt, DTL/TTL compatible 1/8" jack
Optional* Trigger Signal Output
0-5 volt, DTL/TTL compatible 1/8" jack
* on PK2X-AC-OT Model Only
Overcharge Protection
Yes
CE Certification
Yes
Weight
0.9 lbs (415 grams)
Housing Material
High Impact ABS Plastic
Reflector Material
Aluminum
Tripod Mount
1/4-20, female insert
Operating Temp.
32 to 104° F (0 to 40° C)
Dimensions
9–3/4" x 2–3/4" x 1–3/4"
240 x 65 x 40 mm
Warranty
1 year
