The ALM is the high performance line thrower specifically designed for tactical teams. The rugged aluminum launcher is manufactured for use in the most extreme maritime and urban environments to deploy a line, a grappling hook and climbing line, or a grappling hook and tactical ladder for method of entry and vessel boarding from surface or subsurface locations. The ALM is the ultimate tool for tactical teams requiring boat stopping equipment and comes in standard kits with the RGES (Running Gear Entanglement System) SF40.



Utilizing a patented air-thrust technology, the ALM is non-pyrotechnic, re-usable, and re-fillable.

Launcher Assembly housings are cast from 6061-T6 Aircraft Aluminum for the best weight/strength ratio.  The launcher barrels are powder-coated black for covert operations and have a lifetime guarantee against all hazards.

4500 psi / 300 Bar service pressure projectile.

3000 psi / 207 bar service pressure projectile.



MAXimum Distance
The ALM is capable of deploying a 3,200lb test strength line horizontally up to 330 feet / 100 meters. The ALM can deploy a 7.0mm climbing line with a grappling hook vertically up to 165 feet / 50 meters. A 65ft / 20m Tactical Ladder and grappling hook can be fully deployed by the ALM.



MAXimum Safety
The safety mechanism is "always on," re-setting automatically when a projectile is inserted.

The projectile's "Push-Click" engagement allows easy reloading, even in the dark.



A pressure relief burst disk prevents unsafe pressure build-up that could result from exposure to extreme heat.



Each launcher is fitted with a luminous pressure gauge for close visibility at night.



MAXimum Performance
Multi-Shot Capacity.
