The new CHECK-LINE DTMX Digital Tension Meters accurately measure the running line tensions of yarns, fibers, wires, cables, optic fibers and similar process materials.

It's unique design combines the latest microprocessor technology with the reliability, simplicity and ruggedness found in CHECK-LINE mechanical tension meters.

The DTMX provides the critical process information required to meet today's strict quality reporting systems mandated under ISO 9000 guidelines.

• Built-in memory for 100 data values and statistics
• Download capability of stored data and statistics to printers, computers or chart recorders
• Hand-held or continuous on-line use

 Tension Ranges

Model	Range	Outer Roller Spacing c:c	Application Guidelines (Textiles)	Application Guidelines (Wire)
DTMX-200	0.1 - 200.0 g	38 mm	1000 Denier	0.15 mm (max)
DTMX-500	0.1 - 500.0 g	38 mm	0.05-0.25mm	0.05-0.25 mm
DTMX-1K	50 - 1000 g	38 mm	0.10 - 0.40 mm	.10 - 0.25 mm
DTMX-2K	200 - 2000 g	38 mm	0.30 - 0.70 mm	0.30 - 0.70 mm
DTMX-2.5KB	250 - 2500 g	100 mm	0.30 - 0.70 mm	0.30 - 0.70 mm
DTMX-5KB	500 - 5000 g	100 mm	0.50 - 1.20 mm	0.40 - 1.00 mm
DTMX-10KB	1.00 - 10.00 Kg	100 mm	0.70 - 1.40 mm	0.70 - 1.20 mm
DTMXL-20KB*	2.00 - 20.00 Kg	200 mm	1.00 - 2.00 mm	1.50 - 1.70 mm
DTMXL-50KB*	5.00 - 50.00 Kg	200 mm	1.50 - 3.00 mm	1.70 - 3.00 mm
